DTC code	Inspection item
B2416	Height sensor is unusual
B2417	Leveling motor failure
B2418	Leveling motor failure
B241A	Rear height sensor is unusual *
B241B	Front height sensor is unusual *
B2420	EEPROM is unusual
B2450	Initialization is not completed
B2451	Variation write is not completed
B2452	Initialization height sensor data is unusual
B2453	Variation mismatch
U0100	ENG communication blackout

*: B2417 and B2418 are simultaneously output even if abnormality is found in either right or left levering motors.

HINO AUTOMATIC TRANSMISSION (AT) CODE FAILURE

DIAGNOSIS CODE TABLE

DTC code	Diagnosis monitor code	Inspection item
P0500	42	Vehicle sensor system failure
P0562	11	Failure in power supply line
P0705	43	Shift position switch system failure
P0706	44	Abnormality in D range pressure
P0710	38	Oil temperature sensor No.1 system failure
P0715	12	Turbine revolution sensor system failure
P0720	61	Vehicle sensor No.2 system failure
P0725	86	Engine revolution sensor system failure
P0730	37	Abnormal gear ratio
P0746	31	Control valve 1 system failure
P0748	25	Abnormality in linear solenoid 1
P0751	45	Shift valve 1 system failure
P0756	46	Shift valve 2 system failure
P0761	47	Shift valve 3/4 system failure
P0761	48	Shift valve 3/4 system failure
P0776	32	Control valve 2 system failure
P0778	26	Abnormality in linear solenoid 2
P0973	62	Shift solenoid 1 system failure [Low]
P0974	62	Shift solenoid 1 system failure [High]
P0976	63	Shift solenoid 2 system failure [Low]
P0977	63	Shift solenoid 2 system failure [High]
P0979	64	Shift solenoid 3 system failure [Low]
P0980	64	Shift solenoid 3 system failure [High]
P0985	65	Hydraulic control solenoid system failure [Low]
P0986	65	Hydraulic control solenoid system failure [High]
P1604	24	Abnormality in the exhaust brake actuation signal/accelerator opening
P1604	54	Abnormality in the exhaust brake actuation signal/accelerator opening
P1911	51	PTO solenoid system failure [Low]
P2716	28	Pressure control solenoid system failure
P2740	17	Oil temperature sensor No.2 system failure
P2757	33	Control valve 3 system failure
P2759	27	Abnormality in linear solenoid 3
P2764	36	Abnormal lock-up
U0100	88	Engine ECU CAN communication blackout

HINO AIRBAG DIAGNOSTIC TROUBLE CODE

B1000	Air bag computer assembly failure	Air bag computer assembly	Light on
B1615	Assistant seat front sensor malfunction	Air bag sensor assembly No.2 Air bag computer assembly	Light on
B1617	Passenger seat front sensor bus communication blackout	Instrument panel wire, Instrument panel wire No.2 Air bag sensor assembly No.2 Air bag computer assembly	Light on
B1618	Passenger seat front sensor bus initialization failure	Instrument panel wire, Instrument panel wire No.2 Air bag sensor assembly No.2 Air bag computer assembly	Light on
B1652	Partially failed connection of ECU connector	Instrument panel wire Air bag computer assembly	Light on
B1662	Indicator light drive circuit failure	Instrument panel wire Combination meter assembly Air bag computer assembly	Light on
B1800	ignition circuit [short circuit]	Instrument panel wire Horn button assembly Spiral cable Air bag computer assembly	Light on
B1801	Driver air bag ignition circuit [disconnection]	Instrument panel wire Horn button assembly Spiral cable Air bag computer assembly	Light on
B1802	Driver air bag ignition circuit [earth short circuit]	Instrument panel wire Horn button assembly Spiral cable Air bag computer assembly	Light on
B1803	Driver air bag ignition circuit [+B short circuit]	Instrument panel wire Horn button assembly Spiral cable Air bag computer assembly	Light on
B1805*	Passenger air bag ignition circuit [short circuit]	Instrument panel wire, Instrument panel wire No.2 Instrument panel passenger air bag assembly Air bag computer assembly	Light on
B1806*	Passenger air bag ignition circuit [disconnection]	Instrument panel wire, Instrument panel wire No.2 Instrument panel passenger air bag assembly Air bag computer assembly	Light on
B1807*	Passenger air bag ignition circuit [earth short circuit]	Instrument panel wire, Instrument panel wire No.2 Instrument panel passenger air bag assembly Air bag computer assembly	Light on
B1808*	Passenger air bag ignition circuit [+B short circuit]	Instrument panel wire, Instrument panel wire No.2 Instrument panel passenger air bag assembly Air bag computer assembly	Light on
B1900	Driver side pretensioner short circuit	Instrument panel wire Floor wire Front seat outer belt assembly RH Air bag computer assembly	Light on
B1901	Driver side pretensioner open circuit	Instrument panel wire Floor wire Front seat outer belt assembly RH Air bag computer assembly	Light on
B1902	Driver side pretensioner GND short circuit	Instrument panel wire Floor wire Front seat outer belt assembly RH Air bag computer assembly	Light on
B1903	Driver side pretensioner +B short circuit	Instrument panel wire Floor wire Front seat outer belt assembly RH Air bag computer assembly	Light on
B1905*	Passenger side pretensioner short circuit	Instrument panel wire, Instrument panel sub wire Floor wire Front seat outer belt assembly LH Air bag computer assembly wire	Light on
B1906*	Passenger side pretensioner open circuit	Instrument panel wire, Instrument panel sub wire Floor wire Front seat outer belt assembly LH Air bag computer assembly	Light on
B1907*	Passenger side pretensioner GND short circuit	Instrument panel wire, Instrument panel sub wire Floor wire Front seat outer belt assembly LH Air bag computer assembly	Light on
B1908*	Passenger side pretensioner +B short circuit	Instrument panel wire, Instrument panel sub wire Floor wire Front seat outer belt assembly LH Air bag computer assembly	Light on

Диагностические коды HINO

DTC code	Diagnosis monitor code	Diagnosis item
C1201	51	Engine controller failure
C1203	59	Identification signal failure
C1210	36	Yaw rate sensor 0 point uncorrected
C1225	25	BA/TRC solenoid failure
C1232	32	G sensor sticking failure
C1241	41	Power drop
C1243	43	G sensor sticking failure
C1245	45	G sensor output failure
C1249	49	Stop switch sticking detected
C1265	65	Negative pressure sensor failure
C1300	62	ECU failure
C1336	39	G sensor 0 point uncorrected
C1337	37	Abnormal tire size
C1361	91	ABS motor fail-safe relay short-circuit
C1380	64	Stop light drive relay associated failure
C1401	31	Wheel speed sensor FR comparison failure
C1402	32	Wheel speed sensor FL comparison failure
C1403	33	Wheel speed sensor RR comparison failure
C1404	34	Wheel speed sensor RL comparison failure
C1405	31	Wheel speed sensor FR disconnection/short-circuit
C1406	32	Wheel speed sensor FL disconnection/short-circuit
C1407	33	Wheel speed sensor RR disconnection/short-circuit
C1408	34	Wheel speed sensor RL disconnection/short-circuit
C1413	35	Wheel speed sensor FR output failure
C1414	36	Wheel speed sensor FL output failure
C1415	38	Wheel speed sensor RR output failure
C1416	39	Wheel speed sensor RL output failure
C1417	41	IG1 power increase failure
C1418	44	G sensor disconnection/short-circuit
C1419	44	G sensor internal failure
C1420	44	G sensor comparison failure
C1421	46	Master pressure sensor disconnection/short-circuit
C1422	46	Master pressure sensor high 0 point failure
C1423	46	Master pressure sensor low 0 point failure
C1424	46	Master pressure sensor output failure
C1425	49	Stop switch disconnection detection
C1427	51	No motor rotation
C1428	51	Motor circuit failure
C1432	31	Rudder angle sensor power supply voltage failure
C1433	31	Rudder angle sensor internal failure
C1434	31	Rudder angle sensor output failure
C1435	34	Yaw rate sensor internal failure
C1436	34	Yaw rate sensor comparison failure
C1437	65	Engine VSC communication failure [VSC side failure]
C1440	98	Sensor bank judgment failure
C1442	44	Invalid G sensor
C1443	34	Invalid yaw rate sensor
C1468	21	ABS solenoid FR system failure
C1469	22	ABS solenoid FL system failure
C146A	23	ABS solenoid RR system failure
C146B	24	ABS solenoid RL system failure
C146C	13	ABS motor relay circuit disconnection
C146D	14	ABS motor relay short-circuit
C146E	11	ABS solenoid relay circuit disconnection
C146F	12	ABS solenoid relay short-circuit
U0073	94	CAN communication failure
U0100	65	Engine ECU communication failure
U0101	82	Transmission ECU communication failure
U0123	62	Yaw rate sensor communication failure
U0124	95	G sensor communication failure
U0126	63	Rudder angle sensor communication failure
